Vacuum Brazing Furnace

Model

KJ-BV1200

KJ-BV1400

KJ-BV1700

Max. Temperature

1200℃

1400℃

1700℃

Working Temperature

1100℃

1200℃

1600℃

Heating Rate

0-20℃

Heating Element

Resistance Wire

SiC Heating rod

MoSi2 heating rod

Thermocouple

K-type

S-type

B-type

Insulation Material

Alumina ceramic fiber / molybdenum plate

Alumina ceramic fiber / molybdenum plate

Alumina ceramic fiber

Temperature Accuracy

±1℃

Power Supply

110-415V，50/60Hz

Vacuum degree

6.67x10Pa/6.67x10-3Pa

Outside tank

Cooled by fans / water

Size

Heating Chamber Size

mm

Capacity

L

Heating Chamber Size

mm

Capacity

L

150*150*150

3.4

300*300*400

36

150*150*200

4.5

350*350*350

43

200*200*200

8

400*400*400

64

200*200*300

12

400*400*500

80

300*300*300

27

500*500*500

125

Customization is available!

Optional

Crucible, Touchscreen, Software

Notes:

1, In order to ensure the longest possible service life of furnace parts, we recommend heating rate no higher than 10deg.C/min.

2, Cooling rate no higher than 5deg.C/min.

3, Toxic or explosive gas is not allowed.

Warranty

One year warranty with life-time technical support.

Special notes:

1, Consumables like heating element, quartz, crucible and so on are uncovered.

2, Man-made damage and damage caused by misuse are uncovered.
