1600℃ Vertical Tube Furnace
  • 1600℃ Vertical Tube Furnace
  • 1600℃ Vertical Tube Furnace
  • 1600℃ Vertical Tube Furnace
  • 1600℃ Vertical Tube Furnace
  • 1600℃ Vertical Tube Furnace

    Model:KJ-T1600-V

    Description:

    In KJ-T1600-V Vertical Tube Furnace, the tube is placed on a shelf vertically. With alumina ceramic fiber insulation layers, the non-split structure will keep the heat perfectly.

    Specific Introduction:
        This KJ-T1600-V Vertical Tube Furnace is mainly used for nanotube reseach, coating on silicon crystal plate, electrode tests, growth of oxide crystal and so on.

    Parameters:
    Model KJ-T1200-VC KJ-T1200-VD
    Top Temperature 1600℃
    Working Temperature 1500℃
    Tube Diameter
    (Alumina ceramic tube)
    Φ60 Φ80
    Heating zone length 300/440mm
    Insulation layers High-Purity Alumina Ceramic fiber
    Power Supply 110/220/380V 50/60HZ
    Heating Rate 0-20℃/min
    Control Accuracy ±1℃
    Temperature Sensor B-type Thermocouple
    Heating Element Molybdenum Disilicide (MoSi2) Heating rods
    Sealing Flanges
    Structure Non-Split, Vertical
    Accessories Gloves, Crucibles, Tongs, Crucible hook.
    Optional Vacuum pumps, Gas-mixing system with mass flowmeters or float flowmeters.
    Customization is available.
