KJ-T1200-S100 Hot Press Furnace
  • KJ-T1200-S100 Hot Press Furnace
  • KJ-T1200-S100 Hot Press Furnace
  • KJ-T1200-S100 Hot Press Furnace
  • KJ-T1200-S100 Hot Press Furnace
  • KJ-T1200-S100 Hot Press Furnace

    Model:KJ-T1200-S100

    Description:

    KJ-T1200-S100 is a vacuum hot press furnace. Its vacuum chamber is a quartz tube with diameter 100mm. The maximum pressure of the electric press is 20T.

    Brief Introduction:
         KJ-T1200-S100 is a vacuum hot press furnace. Its vacuum chamber is a quartz tube with diameter 100mm. The maximum pressure of the electric press is 20T. This equipment is specially designed to press powder or multi-layer wafers under vacuum or gas protection environment. The maximum temperature of this equipment can reach 1100℃.

    Technical Parameter:
    Model KJ-T1200-S100
    Structure Double layer shell
    Display LED
    Max. Temperature 1200℃
    Continuous working Temperature ≤1100℃
    Heating Rate max. 20℃/min(Suggestion 0~10℃/min)
    Temperature Zone Single zone
    Temperature Control Accuracy ±1℃
    Heating zone length 300mm
      Chamber size OD100 x 300mm
      Tube material Quartz
    Heating Element Resistance wire with Mo
    Thermocouple K Type
    Working Voltage AC 220V single phase, 50 Hz(or according to your requirement)
    Atmosphere Can inject N2, Ar etc.
    Temperature Control 30 steps programmable PID automatic control via SCR power control
    Hydraulic pressure range 0-20T
    Piston diameter Chrome plated cylinders Φ 90 mm
    Oil cylinder stroke 20mm
    Flange Water cooling stainless steel flanges
    Cooling method Water chiller
    Press head material Graphite
    Standard accessories Protective gloves, handle hook, user manual etc.
    Warranty One year limited warranty (Consumable parts such as heating elements are not covered by the warranty)

    hot press tube furnace
