KJ-M1700-DX Muffle Furnace
  • KJ-M1700-DX Muffle Furnace
  • KJ-M1700-DX Muffle Furnace
  • KJ-M1700-DX Muffle Furnace
  • KJ-M1700-DX Muffle Furnace
  • KJ-M1700-DX Muffle Furnace

    Model:KJ-M1700-DX

    Description:

    KJ-M1700-DX high temperature muffle furnace uses MoSi2 rod as heating element. Max. temperature inside furnace can be reached at 1700℃. The furnace temperature profile can be set up by 30 segments and run automatically by the 518P type advanced temperatur

    1. Introduction
    KJ-M1700-DX high temperature muffle furnace uses MoSi2 rod as heating element. Max. temperature inside furnace can be reached at 1700℃. The furnace temperature profile can be set up by 30 segments and run automatically by the 518P type advanced temperature controller. It is excellent for material research, ceramic research labs to develop various new materials.

    1. Technical Specifications
    1 Model KJ-M1700-DX
    2 Inside Chamber Size 120*120*130(mm)
    3 Furnace Structure Double layer steel structure
    4 Standard Working Temperature 1600°C  (continuous)
    5 Maximum Working Temperature 1700°C (< 2 hours)
    6 Temperature Control PID automatic control via SCR (Silicon Controlled Rectifier) power control,
    7 Heating Rate 0 ~20°C / min (suggestion  =< 10°C)
    8 Temperature Accuracy +/- 1°C
    9 Heating Element MoSi2 Heating Element
    10 Thermo Couple B Type
    11 Working Voltage AC 220V, single phase, 50 Hz
    12 Max. Power 2 KW
    13 Warranty One year limited warranty (Consumable parts such as heating elements are not covered by the warranty)
