Range of Application:
This atmosphere furnace is widely used to melt, sinter, analyze metals, non-metal materials and other chemical compound in laboratories, universities and other research institutes.
Parameters：
This atmosphere furnace is widely used to melt, sinter, analyze metals, non-metal materials and other chemical compound in laboratories, universities and other research institutes.
Parameters：
| Model | KJ-A1700-3.4LZ |
| Working Chamber Size | 150*150*150mm |
| Heating Chamber Material | High-Purity Alumina fiber |
| Working temperature | Top temperature: 1700℃ Working temperature: 1600℃ |
| Temperature Control | PID, Intellectual 30-segment Programmable Controller |
| Heating Rate | 0-20℃/min |
| Control Accuracy | ±1℃ |
| Heating Element | Silicon Molybdenum MoSi2 heating rods |
| Temperature Sensor | B-type Thermocouple (With Breakage and over-heating alarm) |
| Outside Shell | Electrostatic sprayed Carbon Steel Outside Shell with Cooling Fans |
| Air-tight Tank | Atmosphere condition and vacuum condition |
| Door | Side-open Design with sealing rubber |
| Power Supply | 220V 50HZ/60HZ （Customizable） |
| Plug | Please let us know the plug in your country when you book the furnace. |
| Max. Power | 3kW |
| Accessories | Crucible Tong, Gloves, Instruction manual |
| Option | Crucible, Screen Control, Software |
| Notes: | 1, In order to ensure the longest possible service life of furnace parts, we recommend heating rate no higher than 10℃/min. 2, Cooling rate no higher than 5℃/min. 3, Toxic or explosive gas is not allowed. 4, It is normal that there will be tiny cracks on the wall of the heating chamber, they won’t affect the performance of the furnace, and can be repaired with alumina coating. |
| Warranty |
One year warranty with life-time technical support. Special notes: 1, Consumables like heating element, quartz, crucible and so on are uncovered. 2, Man-made damage and damage caused by misuse are uncovered. |
