Kejia 1400 Deg.C Atmosphere Furnace
  • Kejia 1400 Deg.C Atmosphere Furnace
  • Kejia 1400 Deg.C Atmosphere Furnace
  • Kejia 1400 Deg.C Atmosphere Furnace
  • Kejia 1400 Deg.C Atmosphere Furnace
  • Kejia 1400 Deg.C Atmosphere Furnace

    Model:KJ-A1400-216LY

    Description:

    Kejia 1400℃ high-temperature atmosphere furnace is suitable for high-temperature sintering, metal annealing, new material development, ashing of organic substances, quality inspection and small batch production in universities, scientific research institu

    Kejia 1400℃ high-temperature atmosphere furnace KJ-A1400-216LY uses silicon carbide rods as heating elements, which can achieve rapid temperature rise; the furnace body adopts a double-layer furnace shell structure, equipped with an air cooling system, and the surface temperature of the furnace shell is lower than 60°C; the furnace door 1. The top of the furnace is sealed with high-temperature silicone rubber, which can be used for pre-vacuumizing or entering a protective atmosphere; double-layer ceramic fiberboard is used, which is energy-saving and environmentally friendly.

    Application:Kejia 1400℃ high-temperature atmosphere furnace is suitable for high-temperature sintering, metal annealing, new material development, ashing of organic substances, quality inspection and small batch production in universities, scientific research institutes, and industrial and mining enterprises.

    Technical Parameters:
    Model KJ-A1400-216LY
    Furnace Structure Carbon steel outside shell with cooling fans, temperature of furnace shell below 60deg.C.
    Carbon steel air-tight tank with three valves for vacuum pump, inlet tube, outlet tube.
    Two layers of ceramic fiber insulation materials
    First layer: 1600deg.C ceramic fiber board
    Second layer: 1400deg.C ceramic fiber board
    Chamber dimension 600*600*600mm
    Max. temperature 1400℃
    Working temp. ≤1300℃
    Heating rate 0-20℃/min (Suggestion: 0-10℃/min)
    Temp. Control accuracy 0.5℃
    Thermocouple S-type thermocouple
    Temp. control PID automatic control via SCR (Silicon controlled rectifier)
    Power control with phase angle fired, current limiting resistor
    30 programmable segments for precise control
    Bulit-in PID auto-tuned function with overheating & broken thermocouple broken protection.
    Over temperature protection and alarm allows for operation without attendant
    Heating element SiC heating rods one the two sides of the heating chamber.
    sic rod
    Working voltage 220V, 50Hz, Three phases(Customized)
    Power 60 kW
    Production period 20 working days
    Warranty Period 1 year (Consumable uncovered.)
