Introduction:
The dual-temperature zone tubular furnace is safe and reliable, easy to operate, has high temperature control precision, good insulation effect, high furnace temperature uniformity, and can be vented to the atmosphere for vacuum. It is widely used in colleges and universities, research institutes, industrial and mining enterprises for high-temperature sintering metal material processing experiments, quality inspection and small batch production.
Features:
(1)Carbon steel outside shell & ceramic fiber lining chamber & double-layer structure with cooling fan
(2)Heat resistance high quality rubber ring for sealing, guarantee good leakproofness.
(4) 30 steps of programmable temperature, PID automatic temperature controller
(5) Independent temperature controller for each hot zone
(6)Combined aural and visual alarm for accident of over temperature & thermocouple broken, and the power supply of the heating part will cut off automatically.
Technical Parameters：
The dual-temperature zone tubular furnace is safe and reliable, easy to operate, has high temperature control precision, good insulation effect, high furnace temperature uniformity, and can be vented to the atmosphere for vacuum. It is widely used in colleges and universities, research institutes, industrial and mining enterprises for high-temperature sintering metal material processing experiments, quality inspection and small batch production.
Features:
(1)Carbon steel outside shell & ceramic fiber lining chamber & double-layer structure with cooling fan
(2)Heat resistance high quality rubber ring for sealing, guarantee good leakproofness.
(4) 30 steps of programmable temperature, PID automatic temperature controller
(5) Independent temperature controller for each hot zone
(6)Combined aural and visual alarm for accident of over temperature & thermocouple broken, and the power supply of the heating part will cut off automatically.
Technical Parameters：
| Model | KJ-TG1100-S60LK2W |
| Tube outer diameter | 60mm (Customization) |
| Unit heat zone length | 220mm (Customization) |
| Total heating zone length | 440mm (Customization) |
| Heat zone number | 2 zone |
| Fiber liner | High purity alumina fiber |
| Thermal couple | N Type |
| Heating element | Resistance wire with Mo |
| Max. temperature | 1200℃ |
| Max working temperature | 1100℃ |
| Temperature Accuracy | ±1℃ |
| Controller | LED |
| Heating rate | 0~20℃/min |
