High temperature rotary furnace equipped with condensation collection tank
  • High temperature rotary furnace equipped with condensation collection tank
  • High temperature rotary furnace equipped with condensation collection tank
  • High temperature rotary furnace equipped with condensation collection tank
  • High temperature rotary furnace equipped with condensation collection tank
  • High temperature rotary furnace equipped with condensation collection tank

    Model:KJ-TX1200-S80LK1W

    Description:

    High-temperature rotary furnaces are used in universities, scientific research institutes, and industrial and mining enterprises for graphene growth, high-temperature atmosphere sintering, atmosphere reduction, CVD experiments, etc.

    Equipment introduction
    The high-temperature rotary furnace equipped with a condensation collection tank is a rotary tube furnace customized according to user needs. A dynamic and static sealing device is installed on the right side and a condensation collection tank is installed. The furnace adopts a lightweight ceramic fiber refined furnace, a double-layer shell structure and an intelligent program temperature control system, with high temperature control accuracy; an air cooling system is equipped between the double-layer furnace shells to effectively reduce the surface temperature of the furnace shell; combined with our company's standard vacuum , Gas mixing system, which can be evacuated and the atmosphere can be evacuated, the furnace body can be tilted, and the furnace tube is made of high-purity quartz tubes of equal diameter. The furnace tube can rotate at 360°C, allowing the material to fully rotate during the rotation process, so that the material is heated more evenly, achieving Better experimental results. High-temperature rotary furnaces are used in universities, scientific research institutes, and industrial and mining enterprises for graphene growth, high-temperature atmosphere sintering, atmosphere reduction, CVD experiments, etc.
    rotary furnace

    Features
    The double-layer shell has an opening structure, making it easy to take in and out the furnace tube, and is equipped with an air cooling system.
    High temperature warning and disconnection prompt functions.
    Stainless steel metal flange, equipped with valves and related interfaces, easy to disassemble and assemble, and can be evacuated and filled with protective gas to a slight positive pressure.
    The lower box of the equipment is a movable box that can also be used as a material rack, making the furnace as a whole easy to move.


    Product name High temperature rotary furnace
    Model KJ-TX1200-S80LK1W
    Shell structure The opening structure on the double-layer shell makes it easy to take and place the furnace tube. Equipped with an air cooling system
    Furnace tube size approx. outer diameter φ80mmX1200mm
    Furnace tube material  Equal diameter high purity quartz tube
    Heating zone length 440mm  ,The length of the constant temperature zone is approx. 200mm
    Working temperature The temperature is not greater than 1100℃ under continuous operation; maximum temperature: 1200℃
    Temperature control method Adopt PID control and self-tuning adjustment, intelligent 30-segment programmable control
    Ultra high temperature alarm With ultra-high temperature alarm
    Broken couple tips There is a reminder of couple breakup
    Furnace chamber size High purity alumina refractory fiber
    Heating rate 0--10℃/min Adjustable (recommended ≤5℃/min for temperatures above 1000 degrees)
    Heating element High quality resistance wire
    Temperature measuring element K type thermocouple
    Working power supply 220V    50HZ    3KW
    Tilt angle Adjustable up to 10 degrees, the angle can be displayed through a digital inclinometer
    Furnace tube speed Maximum 10 rpm (speed adjustable, rotation direction adjustable)
    sealing flange Stainless steel metal flange, with valve and related interfaces, easy to disassemble and assemble, can be evacuated and filled with protective gas to slightly positive pressure
    Moving cabinet The lower box of the equipment is a movable box that can also be used as a material rack, making the furnace as a whole easy to move.
    special requirements A dynamic and static sealing device and a condensation collection tank are installed on the right side.
    Install heating tape between flange and collection tank.
    Warranty 15 months from the date of shipment or 12 months from the date of acceptance (whichever comes first), consumable parts and man-made damage are not covered by the warranty.
    Precautions 1. The air pressure inside the furnace tube is less than 0.02MPa
    2. When introducing gas into the furnace tube, a pressure reducing valve should be installed on the gas cylinder, which will be more accurate and safer to use.
    3. When the equipment is running, it is not recommended to close the air outlet valve and air inlet valve at the flange end of the furnace tube. If you need to close the air valve to heat the sample, you need to always pay attention to the pressure gauge indication. If the air pressure indication is greater than 0.02MPa, you must open the air outlet valve immediately to prevent accidents (such as furnace tube rupture, flange flying out, etc.)
    4. When the furnace is at high temperature, the furnace tube cannot be in a vacuum state. The air pressure in the furnace tube must be equal to the atmospheric pressure and maintained at normal pressure.
    5. Customers are not recommended to use flammable, combustible, corrosive, or toxic materials or gases. If the process must be used, please install relevant safety devices yourself. The company is not responsible for the problems caused.
