  • Double Tube-Tube Furnace


    Continuous Temp:1200℃

    Chamber/Tube size:450+520mm(Dual temperature zone)


    Technical Parameters:
    Model KJ-T1200-S110
    Furnace structure Double-layer shell structure, equipped with a cold air system to automatically cool the temperature of the furnace shell not to exceed 50 ℃
    Furnace material The high-quality and high-purity alumina polycrystalline fiber curing furnace made by vacuum adsorption formed by Japanese technology has good insulation performance, high reflectivity and balanced temperature field.
    Maximum temperature 1200℃
    Continuous working temperature ≤1100℃
    Heating rate Recommended ≤10℃/min, the fastest heating rate is 20℃/min
    Furnace tube material High purity quartz tube (provided by the user)
    Length of heating zone
    (Double furnace)
    450+520mm(Dual temperature zone)
    450+520mm(Dual temperature zone)
    Flange Stainless steel sealing flange, easy to disassemble, with KF25 interface on the two CF flanges
    Temperature Control System The temperature control system adopts artificial intelligence adjustment technology, has PID adjustment and self-tuning functions, and can compile 30 sections of temperature rise and fall programs;
    1. Using PID method to adjust the temperature control, can set 30 sections of temperature rising and falling program
    2. Temperature control accuracy ±1ºC
    3. With over-temperature protection, broken couple protection over-temperature
    4. The instrument has the function of temperature self-tuning
    Heating element Molybdenum alloy resistance wire
    Temperature measuring element K-type thermocouple, independent temperature control in four temperature zones
    Power supply AC380V,50Hz
    Lower box Rectangular box, the front door can be opened, and the bottom feet can be extended into the forklift arm
    Standard configuration 1 host, 2 sealing flanges, 8 sealing rings, 4 furnace plugs, 1 crucible hook, 1 pair of high temperature gloves, 1 manual, 1 certificate of warranty card
