Product introduction:
Kj-c1600-z is a bell jar type sintering furnace, which is a high temperature sintering furnace with periodic operation. The lifting system of shear screw is adopted for the lifting of the burning platform, with constant temperature and long service life. The product can be used in the intermittent production and sintering process of zirconia, alumina, dielectric ceramics and other ceramic products.
Product features:
1. The furnace is fixed with special riveting structure, which will not crack or collapse for a long time.
2. Linear guide rail design, smooth movement without jitter, loading and unloading products are extremely convenient and safe.
3. Corundum mullite is embedded at the bottom of the burning plate to strengthen the support and prevent the burning plate from sinking.
4. Expansion options: tail gas purification furnace, industrial control computer, touch screen integrated control system.
Parameters:
Kj-c1600-z is a bell jar type sintering furnace, which is a high temperature sintering furnace with periodic operation. The lifting system of shear screw is adopted for the lifting of the burning platform, with constant temperature and long service life. The product can be used in the intermittent production and sintering process of zirconia, alumina, dielectric ceramics and other ceramic products.
Product features:
1. The furnace is fixed with special riveting structure, which will not crack or collapse for a long time.
2. Linear guide rail design, smooth movement without jitter, loading and unloading products are extremely convenient and safe.
3. Corundum mullite is embedded at the bottom of the burning plate to strengthen the support and prevent the burning plate from sinking.
4. Expansion options: tail gas purification furnace, industrial control computer, touch screen integrated control system.
Parameters:
| product name | 5G ceramic filter bell furnace |
| model | KJ-C1600-Z |
| Maximum temperature | 1200 ~ 1700 ℃ |
| Operating temperature | 1200 ~ 1600 ℃ |
| Furnace size | 400 × 400 × 450mm ~ 1200 × 600 × 600mm |
| Heating element | Silicon molybdenum rod |
| Operating Voltage | 380V |
| Maximum power | 36KW ~ 110KW |
| Temperature control method | Multi-stage program temperature control |
| Temperature control protection | Over-temperature protection function, over-temperature automatic power off |
| After-sales service | One year warranty, lifetime maintenance |
| More specifications can be customized according to demand | |
