A brief description:
High-temperature alloy steel bright annealing furnace application range: bright annealing of tool steel, die steel, ultra-high-strength steel, high-temperature alloy steel, stainless steel, magnetic materials, titanium alloys, non-ferrous metals and other materials...
Application range:
Bright annealing of tool steel, die steel, ultra-high strength steel, high temperature alloy steel, stainless steel, magnetic materials, titanium alloy, non-ferrous metals and other materials.
Product features:
1. Realize high vacuum to ensure workpiece processing quality
2. Heating The components are evenly arranged to ensure the uniformity of the furnace temperature
3. Metal molybdenum heating, stainless steel heat preservation, high furnace cleanliness
4. The touch screen interface is friendly and practical, which can display and monitor the operating status of the equipment, and can call, edit and store the sintering process, and is dynamic Display, historical data can be recorded and exported
5. With safety interlock, fault diagnosis and abnormal alarm function
Technical parameters:
Bright annealing of tool steel, die steel, ultra-high strength steel, high temperature alloy steel, stainless steel, magnetic materials, titanium alloy, non-ferrous metals and other materials.
Product features:
1. Realize high vacuum to ensure workpiece processing quality
2. Heating The components are evenly arranged to ensure the uniformity of the furnace temperature
3. Metal molybdenum heating, stainless steel heat preservation, high furnace cleanliness
4. The touch screen interface is friendly and practical, which can display and monitor the operating status of the equipment, and can call, edit and store the sintering process, and is dynamic Display, historical data can be recorded and exported
5. With safety interlock, fault diagnosis and abnormal alarm function
Technical parameters:
| Model | KJ-JS223 (optional) | KJ-JS334 (optional) | KJ-JS446 (optional) | KJ-JS557 (optional) | KJ-JS669 |
| Heating area (mm) Customizable |
200×200×300 | 300×300×400 | 400×400×600 | 500×500×700 | 600×600×900 |
| Heating power (Kw) | 25 | 50 | 75 | 95 | 150 |
| Maximum temperature (℃) | 1350 | 1350 | 1350 | 1350 | 1350 |
| Ultimate vacuum (Pa) | 10pa, 6.7×10-3pa | ||||
| Heating element | Metal molybdenum belt | ||||
| Structure | Single indoor thermal horizontal structure | ||||
| Heating rate | 0-20℃/min | ||||
| More specifications can be customized according to requirements | |||||
